1794-OE4
1794 Flex, Flex Ex, Flex XT I/O System
1794 Flex, Flex Ex, Flex XT I/O System, Analog Output Modules, 4 Single-Ended Outputs
| Technical specifications for 1794-OE4 | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Output Analog Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-OE4 |
| GTIN | 10612598137876 |
| Weight | 0.25 lbs (0.11 kg) |
| Conversion Type | Pulse Width modulation |
| Data Format | left justified, 16 bit 2s complement |
| Resolution | 12 bits plus sign Voltage: 2.56mV/cnt Current: 5.13µA/cnt |
| Product Description | Flex IO High Density Analog Output Module |
| No. of inputs | Four (4) Single Ended |
| Output type | 0 to 20 mA; 4 to 20 mA; +/- 10VDC; 0 to 10 VDC |
| Conversion Rate | 1.024ms maximum all channels |
| Terminal base | 1794-TB2, -TB3, -TB3S, -TB3T, -TB3TS, and -TBN |
| Indicators | 1 green/red power/status indicator |
| External DC supply, nom | 24V DC |
| External DC supply range | 10.0…31.2V DC (includes 5% AC ripple) |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | –40…85 °C (–40…185 °F) |
| Vibration | 5g @ 10 to 500 Hz |
| Outputs | 4 Single-ended |
| Output Current Terminal | 4 to 20 mA |
| Output Voltage Terminal | +/- 10 Volts |
| Current Load on Voltage Output | 3 mA maximum |
| Flexbus Current | 20 mA |
| Power Dissipation | 4.5 W at 31.2 Volts DC maximum |
| Thermal Dissipation | 13.6 BTU/hour at 31.2 Volts DC maximum |
