2711-T14C20
The 2711-T14C20 operator interface terminal has been designed and manufactured by Allen-Bradley/Rockwell Automation in the Panelview 1400 series. It operates at 85 to 264 Volts AC and at 47 to 63 Hertz. The 2711-T14C20 operator interface terminal has a 14-inch touchscreen with color graphics for control and data input. Its communication port supports the industrial Ethernet network. The 2711-T14C20 operator interface terminal can operate at an ambient temperature from 0 to 55 degrees Celsius or 32 to 131 degrees Fahrenheit.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711-T14C20 |
| Power Type | AC |
| Supply Voltage Limit | 85-264 Volts; 43-63 Hertz |
| Power Consumption | 200 VA max |
| Comm Port | Ethernet |
| Total Application Flash Memory | 1008 Kbytes |
| Operating Shock | 15 g |
| Non-Operating Shock | 30 g |
| Operating Temperature | 32-131 F (0-55 C) |
| Dimensions | 13.97 x 17.37 x 15.53 in (355 x 441 x 394 mm) |
| Display Dimensions | 10.0 x 7.5 in (255 x 191 mm) |
| Weight | 43.2 lbs (19.6 kg) |
| Method of Input | Touchscreen |
