Technical Specifications for 2711P-K15C6B2
The 2711P-K15C6B2 is a Human Machine Interface (HMI) device from Allen-Bradley’s PanelView Plus Product category. This operator terminal is part of the PanelView Plus 1500 which has a supply voltage range of 18-32 VDC / 85-264 VAC, 47-63 Hz. This terminal is equipped with a colored display 15-inch screen with resolution of 1024 x 768 pixels. It is equipped with keypad operator interface and communicates with partner automation devices through the embedded Data Highway Plus (DH+), DH-485, and RS232 communication interfaces. It is also provided with USB interfaces that allows insertion of peripheral devices.
Brand: Rockwell Automation / Allen-Bradley
PV PLUS 1500, KEYPAD, RIO/DH, AC PS, EXT MEM INCL RIO, DH+, DH-485, ETHERNET, RS232, USB
| Manufacturer | Rockwell Automation |
| Keypad function keys: | F1 to F20, K1 to K20; 0…9, Special Characters, Backspace, Enter, Left and Right Tab, keys, Shift keys |
| Keypad: | 1 million presses |
| Resolution: | 1024 x 768 18-bit color graphics |
| Display Area: | 304 x 228 mm (12.0 x 9.0 in.) |
| Display Size: | 15.0 inches |
| Backlight: | 50,000 hrs |
| Lifecycle status: | Active |
| Operator Input: | Keypad |
| Product Type: | Operator Terminals |
| Product Family: | PanelView Plus 1500 Standard Terminals |
| Brand | Allen-Bradley |
| Integrated ports: | DH+/ RIO, DH-485, Ethernet, RS-232, 2 USB host |
| Display Type | Color active matrix, thin-film transistor (TFT) |
| Input Voltage range: | 85-264VAC, 47-63 Hz |
| Manufacturer: | Rockwell Automation |
| Part Number/Catalog No. | 2711P-K15C6B2 |
| Series | Panelview Plus 1500 |
| Brand | Allen-Bradley |
| Input Method | Keypad Input |
| Product Family: | PanelView Plus |
| Communicaion Ports | DH+/RIO/DH-485 Communication ports |
| Product Type: | PanelView Plus 1500 |
| Power | VDC/VAC Input |
| Part Number: | 2711P-K15C6B2 |
| Input interfaces: | Keypad |
| Features | 128 MB |
| Display Type: | Color Active Matrix TFT display |
| Resolution: | 1024 x 768 |
| Product Lifecycle Status* | Discontinued/Obsolete |
| Input interface lifespan: | 1 million presses |
| Real-time clock: | Battery-backed clock timestamps critical data |
| Battery: | Replaceable with part number 2711P-RY2032 |
| Communication interface: | Ethernet; RS232; USB |
| Input Voltage range: | 18-32 VDC / 85-264 VAC |
| Input frequency: | 47-63 Hz |
| Enclosure: | NEMA Type 12/13, 4X (Indoor use only), IP54, IP65 |
