1769-OF8C
1768 / 1769 CompactLogix System
8 Channel Analog Current Output Module
| Technical specifications for 1769-OF8C | |
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | CompactLogix |
| Part Number | 1769-OF8C |
| UPC | 662468861625 |
| Weight | 1.00 lbs (0.45 kg) |
| Series | 1769 Compact I/O |
| Module Type | Analog Output Module |
| No. of Outputs | Eight (8) Current outputs |
| Output Current | 0-20 mA / 4-20 mA |
| Output Current Range | 0-21 mA; 3.2 mA – 21 mA |
| Resolution | 16 bit |
| Conversion Rate (all channels) max. | 5 ms |
| Overall Accuracy | ±0.35% full scale at 25°C |
| Open and Short-Circuit Protection | Yes |
| Maximum Short-Circuit Current | 21 mA |
| Current draw | 145 mA at 5VDC; 185 mA at 24V dc |
| Channel Diagnostics | Over- or under-range by bit reporting output wire broken or load resistance high by bit reporting |
| Enclosure | None |
| Input Type | Output Current |
| Communication Cable | 8 Point |
| Converter Type | Delta Sigma |
| Outputs | 8 single-ended |
| Replacement Door Part Number | 1769-RD |
| Wire Type | Copper-90 degrees |
| Solid Wire Size | 22 to 14 AWG |
| Stranded Wire Size | 22 to 16 AWG |
| Heat dissipation | 2.69 Watts |
