2080-MOT-HSC
2080 Micro800 System
2080 Micro800 System, High Speed Counter, 4 inputs with Line Driver, 250KHz
| Technical specifications for 2080-MOT-HSC | |
| Manufacturer | Allen Bradley |
| Product Type | High-speed counter plug-in module |
| Product Line | Micro 800 |
| Part Number | 2080-MOT-HSC |
| Weight | 0.19 lbs (0.09 kg) |
| Input Type | Quadrature differential (A, B, Z) channels |
| Number of Inputs | 1 channel (ABZ) |
| Input Voltage Range | 0 – 30 V DC |
| Input Current Range | 2 – 9 mA typical |
| Input Frequency (Max) | 250 kHz (50 % duty cycle) |
| Input Impedance (Nominal) | 3.58 kΩ |
| Minimum Pulse Width | 2 µs |
| Output Channels | 1 physical + 15 virtual |
| Output Voltage Range | 5 – 30 V DC |
| Output Current (Max) | 0.5 A per output |
| Output Switching Time | ≤ 2 ms on/off |
| Bus Power Draw | 60 mA @ 3.3 V DC |
| Isolation Voltage | 50 V continuous (tested @ 720 V DC for 60 s) |
