2080-OF2
2080 Micro800 System
2080 Micro800 System, 2-ch V/I Analog Output Unipolar 0-10V/0-20mA (non-isolated)
| Technical specifications for 2080-OF2 | |
| Manufacturer | Allen Bradley |
| Product Type | Analog Plug-in Module |
| Product Line | Micro 800 |
| Part Number | 2080-OF2 |
| UPC | 885630058412 |
| Weight | 0.13 lbs (0.06 kg) |
| Number of Single Ended Outputs | 2 |
| Analog Normal Operating Voltage Range | 10V DC |
| Analog Normal Operating Current Range | 0-20mA |
| Resolution max. | 2.5 ms |
| Step Response to 63% | 5 ms |
| Current Load In Voltage Output max. | 10 mA |
| Repeatability | +/- 0.1% |
| Input Group to Bus Isolation | No Isolation |
| Channel to Channel Isolation | Non-Isolation |
| Cable Length max. | 10 m |
