25B-D010N114
Allen Bradley Inverter Drive, 4 kW, 3 Phase, 400 V ac, 10.5 A, PowerFlex 525 Series
| Technical specifications for 25B-D010N114 | |
| Manufacturer | Allen Bradley |
| Category | Drives |
| Product Line | PowerFlex 525 |
| Part Number | 25B-D010N114 |
| UPC | 884951886032 |
| Weight | 3.81 lbs (1.73 kg) |
| Output Current | 10.5 A |
| Product Family | PowerFlex 525 Adjustable Frequency AC Drive |
| Input Voltage | 380-480VAC |
| Input Phase | 3-Phase |
| Output Voltage | 0-460VAC |
| Output Power | 4.0 kW (5.0 HP) |
| I/O | Discrete Inputs: Seven (7) Inputs Discrete Outputs: Two (2) Opto Outputs and Two (2) Relay Outputs Analog Input: Two (2) Analog Input Analog output: One (1) analog output |
| Installation | Panel Mount |
| Enclosure Rating | IP20 / NEMA UL Open Type |
| Frame | B |
| Control Method | Volts / Hertz Control; Sensorless Vector Control |
| Built-in communication port | RS485; Ethernet |
| Optional communication protocols | ProfiBus; Ethernet; DeviceNet; |
| Integrated Safety | Safe-Torque Off (STO) functionality |
| EMC Filter | Integrated |
| Series | PowerFlex 525 Drive |
| Voltage | Three Phase, 480 VAC |
| Enclosure Type | IP20 NEMA / Open Type |
| Interface Module | Standard |
| Frame Size | Frame B |
| EMC Filtering Options | Filter |
