5069-IA16
Compact 5000 AC Input Module
| Technical specifications for 5069-IA16 | |
| Module Type | Digital AC Input Module |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 5069-IA16 |
| Manufacturer | Rockwell Automation |
| Series | Compact 5000 I/O |
| No. of Inputs | Sixteen (16) Inputs |
| Input Voltage | 120 / 240 VAC |
| Operating Voltage Range | 79-265 VAC |
| Module Keying | Electronic |
| Input Delay Time, OFF to ON | 10 ms (typ) + filter time |
| Power Dissipation (Max) | 3.5 W |
| MOD Power | 75 mA @ 18…32V DC |
| MOD Power passthrough, max | 9.55 A @ 18…32V DC |
| SA Power | 240 mA @ 79…264V AC |
| SA Power Passthrough, max | 9.975 A @ 79…264V AC |
| Thermal Dissipation | 11.9 BTU/hr |
| Removable Terminal Block(s) | 5069-RTB18-SPRING RTB; 5069-RTB18-SCREW RTB |
| Number of Inputs | 1 Group of 16 Channels |
| Number of Outputs | N/A |
| Voltage Category | 120/240 Volts AC |
| Input Voltage Range | 79-264 Volts AC |
| Output Voltage Range | N/A |
| Power Dissipation | 3.5 Watts |
| Enclosure Type | None (Open Style) |
| Dimensions | 5.4 x 0.9 x 4.2 in (138 x 22 x 105 mm) |
| Weight | 0.39 lbs (175 g) |
| UPC | 889508141602 |
