5069-OW16
5069 CompactLogix/Compact GuardLogix System
5069 Compact I/O 16 channels non isolated normally open relay output module.
| Technical specifications for 5069-OW16 | |
| Output Voltage Range | 5-125VDC; 5-264VAC |
| Module Type | Relay output module |
| Part Number/Catalog No. | 5069-OW16 |
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Series | Compact 5000 I/O |
| No. of Inputs | Sixteen (16) Form A contacts |
| Relay Ratings | 2 A resistive per channel @ 5…30V DC; 2 Aresistive per channel @ 5…264V AC, 50/60 Hz; 2 A general use per channel @ 5…250V AC, 50/60 Hz and 2 A @ 5…125V AC, ATEX/IECEx. |
| Pilot duty rating | 5…240V AC, 50/60 Hz, C300 pilot duty per channel 5…125V DC, R150 pilot duty per channel |
| Output current per group, max | 8:00 AM |
| Output current per module, max | 16 A |
| Output Delay Time | 10 ms |
| Switching frequency | 1 operation every 3 seconds (0.3 Hz at rated load) |
| Initial contact resistance, max | 30 |
| Bounce time, mean | 500 µs |
| Fusing | Outputs are not fused |
| Expected contact life | 300K cycles resistive, 100K cycles inductive |
| Number of Inputs | N/A |
| Number of Outputs | 16 (2 Groups of 8) N.O. |
| Voltage Category | N/A |
| Input Voltage Range | N/A |
| Power Dissipation | 3.0 Watts |
| Enclosure Type | None (Open Style) |
| Dimensions | 5.4 x 1.4 x 4.2 in (138 x 36 x 105 mm) |
| Weight | 0.53 lbs (240 g) |
| CIP Sync Supported | Yes |
| Pattern Matching Supported | Yes |
