5094-OB16 | Allen-Bradley Flex 5000 Output Module, 24VDC, 16 Outputs
| Brand | Allen-Bradley |
| Manufacturer | Rockwell Automation |
| Part Number | 5094-OB16 |
| Module Type | T Safety Digital 16-point Sourcing Output Module |
| On-state voltage range | 18…32V DC |
| On-state voltage drop, max | 0.25V DC |
| On-state current per channel, min | 1 mA |
| Off-state voltage, max | 5V DC with 1 mA min load |
| Off-state leakage current per point, max | 0.5 mA per point |
| Output current rating, max | 0.5 A per channel |
| Surge current per point | 1 A max for 10 ms per point, repeatable every 2 s |
| Output delay time (backplane to screw), max for Off to On and On to Off | 100 μs @ 25 °C (77 °F) @ 0.5 A100 μs @ 25 °C (77 °F) @ 0.5 A |
| Pulse width, min | ≤ 200 μs (Ton + Toff) @ 0.5 A @ 25 °C (77 °F) |
| Output drift | ±400 ns/°C -40…70 °C @ 0.5 A |
| Open load detection diagnostics | Yes |
