1794-IB8
ALLEN-BRADLEY Flex 8 Point Digital Input Module
1794 Flex, Flex Ex, Flex XT I/O System, Input Module, 24VDC, 8 Sink Inputs
| Technical specifications for 1794-IB8 | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Digital Input Modules |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IB8 |
| UPC | 612598181285 |
| Weight | 0.19 lbs (0.09 kg) |
| Inputs | 8 Current Sinking |
| On-state Voltage min. | 10V DC |
| On-state Voltage max. | 31.2V DC |
| On-state Current min. | 2.0mA min. |
| On-state Current max. | 12.0mA |
| Off-state Voltage max. | 5V DC |
| Off-state Current max. | 1.5mA |
| Flexbus Current | 20mA @ 5V DC |
| Power Dissipation | 3.5W @ 31.2V DC max. |
