1794-ACNR15
Flex Controlnet Adapter
1794 Flex, Flex Ex, Flex XT I/O System, ControlNet FLEX I/O Adapter Module
| Technical specifications for 1794-ACNR15 | |
| Manufacturer | Allen Bradley |
| Product Type | Redundant Media ControlNet Adapter |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-ACNR15 |
| UPC | 612598180592 |
| Weight | 0.56 lbs (0.26 kg) |
| Power Dissipation | 3.4W maximum @ 19.2V dc |
| Product Description | Redundant ControlNet Adapter Module |
| Communication Port | Two (2) ControlNet BNC |
| Data Transfer speed | 5 Mbps |
| Indicators | Comm A: red/grn Comm B: red/grn I/O status- red/grn |
| Mounting | DIN Rail |
| ControlNet Protocol | V 1.25 |
| ControlNet cable | 3.31 mm2 (12 AWG) stranded max 1.2 mm (3/64 in.), insulation, max |
| Operating Temperature | -20…55 °C -4…131 °F) |
| Surrounding Temperature | 55 °C (131 °F) |
| Power Consumption | 400mA maximum from external 24V supply |
| Thermal Dissipation | 15.7 BTU/hr @ 19.2V dc |
| Voltage | 24 V DC |
| Input Voltage Range | 19.2-31.2V DC |
| Flexbus Output Current | 640 mA max. |
| Isolation Voltage | 850V DC |
| Inrush Current | 23A for 2ms |
| Communication Rate | 5M bps |
| Current Draw | 450mA max. |
