1794-AENT
ALLEN-BRADLEY Flex EtherNet/IP Adaptor
1794 Flex, Flex Ex, Flex XT I/O System, EtherNet/IP 10/100 Mbit FLEX I/O Adapter Module
| Technical specifications for 1794-AENT | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Ethernet/IP Adapter |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-AENT |
| UPC | 612598279845 |
| Weight | 0.44 lbs (0.20 kg) |
| Thermal Dissipation | 24.9 BTU/hr @ 19.2V DC |
| Power Dissipation | 7.3 W max @ 19.2V DC |
| Power Consumption | 550 mA max, 440 mA max at 24V DC |
| Product Description | Ethernet Adapter Module |
| Communication Port | One (1) RJ45 |
| Supported Protocol | Ethernet I/P |
| Supported topologies | Linear |
| Data Transfer speed | 10 to 100 Mbps |
| Indicators | Mod Status; Network Status; Link Status |
| Mounting | DIN Rail |
| Ethernet cable | RJ45 Cat.5 |
| Wire Size | 0.34…2.5 mm2 (22…12 AWG) stranded copper wire rated at 75 °C (167 °F) or higher, 1.2 mm (3/64 in.) insulation max |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | Tested 5 g @ 10-500Hz per IEC 68-2-6 |
| Operating Shock | 30 g peak acceleration, 11(+1)ms pulse width |
| I/O Capacity | 8 Modules |
| Communication Rate | 10/100 Mbps |
| Input Voltage Range | 19.2 to 31.2 Volts DC |
| Nominal Input Voltage Rating | 24 Volts DC |
| Enclosure Type Rating | None (open-style) |
| Isolation Voltage | 50 Volts Continuous |
| Flexbus Current | 640 mA maximum |
