1769-OW16
Allen-Bradley
I/O Module, 16 Compact Digital Outputs, 5 – 265VAC, 5-125VDC
| Technical specifications for 1769-OW16 | |
| Manufacturer | Allen Bradley |
| Product Type | Discrete Output Module |
| Product Line | CompactLogix |
| Part Number | 1769-OW16 |
| UPC | 612598286232 |
| Weight | 1.00 lbs (0.45 kg) |
| Product Family | Compact I/O |
| Module Type | Relay Output Module |
| Operating Voltage | 5 to 265 Volts AC or 5 to 125 Volts DC |
| No. of outputs | Sixteen (16) |
| Enclosure Type | Open |
| No. of Groups | 2 |
| No. of Channels per group | 8 |
| Communication Cable | 16 Point |
| Outputs | 16 Normally Open (8 points/group) |
| Operating Temperature | 0 to 60 degrees Celsius |
| Compatible controllers | MicroLogix 1500; CompactLogix controllers |
| Series | A and B |
| Output Type | AC/DC normally open relay |
| Operating Voltage range | 5 to 265V ac 5 to 125V dc |
| Signal delay, On | 10 ms |
| Wire Type | Copper-90 |
| Solid Wire Size | 22 to 14 AWG |
| Bus Current draw, 5.1 V | 125 mA |
| Bus Current draw, 24 V | 100 mA |
| Heat Dissipation | 2.83 Watts |
| Slot width | 1 |
| Stranded Wire Size | 22 to16 AWG |
| Current per Module | 20 Amps |
