Kinetix 5700 Dual Axis Safe Speed Drive Servo Drive
2×5.0 Arms continuous, 2×12.0 Arms Peak output current – Advanced Safety
| Technical specifications for 2198-D012-ERS4 | |
| Manufacturer | Allen Bradley |
| Category | Drives |
| Product Line | Kinetix 5700 |
| Part Number | 2198-D012-ERS4 |
| Weight | 6.00 lbs (2.72 kg) |
| Per Axis | X |
| Module Type | Dual-axis Inverter |
| Bandwidth Velocity loop, max and Current loop | 400 Hz, 1000 Hz |
| AC input frequency | 4 kHz |
| Continuous output current (rms) | 5.0 A |
| Continuous output current (0-pk) | 7.0 A |
| Continuous power out (nom) 324…528V rms, three-phase | 3.4 kW |
| DC input current @ 458…747V DC | 5.3 ADC |
| Internal Capacitance | 165 μF |
