1762-OB32T
ALLEN-BRADLEY MicroLogix 32 Point D/O Module
1762 MicroLogix 1200 System, 32 Point 24 VDC Source Output Module
| Technical specifications for 1762-OB32T | |
| Manufacturer | Allen Bradley |
| Product Type | Source Output Module |
| Product Line | MicroLogix 1200 |
| Part Number | 1762-OB32T |
| UPC | 612598849925 |
| Weight | 0.31 lbs (0.14 kg) |
| Series | MicroLogix |
| Module Type | Solid State output module |
| No. of Outputs | Thirty-Two (32) ouputs |
| No. of groups | Two (2) Output groups |
| Channels per group | Sixteen (16) channels |
| Nominal Output voltage | 24VDC |
| Output voltage range | 10.2-26.4 VDC |
| Output current rating per channel | 0.5 A @ 60 °C (140 °F) |
| Output current rating per group | 2.0 A @ 60 °C (140 °F) |
| Output current rating per module | 4.0 A @ 60 °C (140 °F) |
| Surge current | 2.0 A (Repeatable every 2 s @ 60 °C (140 °F) for 10 ms |
| Minimum On-state current | 1 mA |
| Outputs | 32 |
| Input Power | 24V DC |
| Operating Voltage Range | 10.2-26.4V DC |
| Heat Dissipation | 3.4 Watts |
| Wire Size | 22, 24, and 26 AWG |
