1769-PA4
Allen-Bradley
Power Supply, 85 – 265VAC/170 – 265VAC Input, 120/220VAC Ouput, 18W, 25A
| Technical specifications for 1769-PA4 | |
| Manufacturer | Allen Bradley |
| Product Type | I/O Power Supply |
| Product Line | CompactLogix |
| Part Number | 1769-PA4 |
| GTIN | 10612598276889 |
| Weight | 1.00 lbs (0.45 kg) |
| Module Type | AC Power Supply Module |
| Input Power | 120 Volts AC |
| Input Voltage range | 85…265V AC or 170…265V AC, switch selectable |
| Power Supply Distance Rating | 8; 8 I/O modules can be connected on either side of the power supply for a maximum of 16 module. |
| Input frequency range | 47…63 Hz |
| Power consumption | 200 VA @ 120V AC 240 VA @ 240V AC |
| Enclosure Type | None (Open Style) |
| Power dissipation | 8 W @ 60 °C (140 °F) |
| Series | A and B |
| Current capacity @ 5V DC | 4.0 A |
| Current capacity @ 24V DC | 2.0 A |
| Wire Type | Copper wire withstanding 90 degrees Celsius |
| Inrush current, max | 25 A @ 132V AC |
