20F1AND156AA0NNNNN is part of the PowerFlex 753 Adjustable Frequency AC drive
| Part Number/Catalog No. | 20F1AND156AA0NNNNN |
| Brand | Allen-Bradley |
| Series | PowerFlex 753 |
| Control Method | V/Hz control, vector control with FORCE™ technology and sensorless vector control. |
| Enclosure Rating | IP20/IP00, NEMA/UL Type Open |
| Voltage Rating | 480V AC, 3-Phase |
| Continuous Output Power, ND | 125 Hp |
| Continuous Output Current, HD | 125 Amperes |
| Continuous Output Power, HD | 100 HP |
| DC Filtering | Yes |
| Default CM Cap Connection | Jumper Installed |
| Internal Resistor | No |
| Human Interface Module (HIM) | Not Included |
| Mounting | Panel Mounted |
| Premiere Integration: | Supported |
| Voltage Class | 480 AC Volts |
| Output Current | 156 Amperes |
| Phase Count | Three |
| Frame Size | 6 |
| Enclosure Type | IP00 (IP20 NEMA) |
| EMC Filtering Options | Filtered, No CM Jumper |
| Input Type | AC Input with Precharge |
| Dynamic Breaking | DB Transistor |
| Weight | 85 lbs |
| Dimensions | 26.20 x 12.13 x 13.64 in |
