20F1AGD248JA0NNNNN — PowerFlex Air Cooled 753 AC Drive
ALLEN-BRADLEY PowerFlex 753 AC Drive, with Embedded I/O, Standard Protection, Forced Air, AC Input with Precharge, no DC Terminals, Type 12 / IP54, 248 Amps, 200HP ND, 150HP HD, 480 VAC, 3 PH, Frame 7, Filtered, CM jumper installed (preferred), DB Transistor, Blank (No HIM)
| Technical specifications for 20F1AGD248JA0NNNNN | |
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AGD248JA0NNNNN |
| Weight | 275.00 lbs (124.74 kg) |
| Input Type | AC Input with Precharge, no DC Terminals |
| Enclosure | IP 54, NEMA/UL Type 12 |
| Voltage Rating | 480 Volts AC |
| Horsepower | 200 HP |
| CM Capacitor Connection | Jumper Installed |
| Filtering | Yes |
| Dynamic Braking | Optional with Braking Transistor |
| Interface | No Human Interface Module |
| Cooling Method | Forced Air |
| Frequency | 60 Hz |
| Input Phase | 3-Phase |
| Frame Size | Frame 6 |
| Compliance / Listings | UL; CE; CSA |
