20F1AGC367JA0NNNNN — PowerFlex Air Cooled 753 AC Drive
ALLEN-BRADLEY PowerFlex 753 AC Drive, with Embedded I/O, Standard Protection, Forced Air, AC Input with Precharge, no DC Terminals, Type 12 / IP54, 367 Amps, 200kW ND, 160kW HD, 400 VAC, 3 PH, Frame 7, Filtered, CM jumper installed (preferred), DB Transistor, Blank (No HIM)
| Technical specifications for 20F1AGC367JA0NNNNN | |
| Manufacturer | Allen Bradley |
| Product Type | Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AGC367JA0NNNNN |
| Weight | 32.00 lbs (14.51 kg) |
| Input Type | AC Input with Precharge, no DC Terminals |
| Enclosure | IP54, NEMA/UL Type 12 |
| Voltage Rating | 400V AC / 540V DC |
| Current Rating | 367 Amps |
| Power Rating | 200 kW |
| Filtering | Yes |
| Default CM Cap Connection | Jumper installed |
| Internal Resistor | No |
| Internal Transistor | Yes |
| Door Mounted HIM | No Door Mounted HIM |
| Temperature | 0 to 40 °C |
| Storage Temperature | -40 to 70 °C |
| Relative Humidity | 5 to 95% |
| Certifications | CE, ABS, EAC, KCC |
