20F1AGD096JA0NNNNN — PowerFlex Air Cooled 753 AC Drive
ALLEN-BRADLEY PowerFlex 753 AC Drive, with Embedded I/O, Standard Protection, Forced Air, AC Input with Precharge, no DC Terminals, Type 12 / IP54, 96 Amps, 75HP ND, 60HP HD, 480 VAC, 3 PH, Frame 6, Filtered, CM jumper installed (preferred), DB Transistor, Blank (No HIM)
| Technical specifications for 20F1AGD096JA0NNNNN | |
| Manufacturer | Allen Bradley |
| Product Type | Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AGD096JA0NNNNN |
| Weight | 275.00 lbs (124.74 kg) |
| Input Type | AC Input with Precharge, no DC Terminals |
| Enclosure | IP54, NEMA/UL Type 12 |
| Voltage Rating | 480V AC / 650V DC |
| Current Rating | 96 Amps |
| Power Rating | 75 Hp |
| Filtering | Yes |
| Default CM Cap Connection | Jumper installed |
| Internal Resistor | No |
| Internal Transistor | Yes |
| Door Mounted HIM | No Door Mounted HIM |
| Temperature | 0 to 40 °C |
| Storage Temperature | -40 to 70 °C |
| Relative Humidity | 5 to 95% |
| Certifications | CE, ABS, EAC, KCC |
