20F1AGD302AN0NNNNN — PowerFlex Air Cooled 753 AC Drive
ALLEN-BRADLEY PowerFlex Air Cooled 753 AC Drive
| Technical specifications for 20F1AGD302AN0NNNNN | |
| Manufacturer | Allen Bradley |
| Product Type | Variable Frequency Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AGD302AN0NNNNN |
| Weight | 32.00 lbs (14.51 kg) |
| Voltage | 480 V, 3Ø |
| Output Current | 302 A |
| I/O Capacity | Digital, analog, relay expandables |
| Motor Control | V/Hz, SVC, FVC, PM |
| Stop Functions | Coast, ramp, DC, fast, hold |
| Operating Temperature | 0–40 °C |
| Storage Temperature | -40–70 °C |
| Cooling | Fan, cabinet mount |
| Power Rating | 250 HP ND / 200 HP HD |
| Peak Current | 332 A (1 min), 453 A (3 s) |
| Overload | ND: 110%/60 s, 150%/3 s; HD: 150%/60 s, 180%/3 s |
| Input Design | 6-pulse with precharge |
| EMC Filter | Integrated |
