1794-IP4
Flex 4 Point Distributed I/O Comb Module
1794 Flex, Flex Ex, Flex XT I/O System, Input Module, 4-Channel 12/24VDC Pulse Counter
| Technical specifications for 1794-IP4 | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O 4 Channel Pulse Counter Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IP4 |
| UPC | 612598184262 |
| Weight | 0.25 lbs (0.11 kg) |
| Product Description | Flex IO Pulse counter module |
| Number of Inputs | Four (4) |
| No. of input groups | Two (2) |
| Minimum Pulse width | 2 s |
| Input Frequency | 100 kHz |
| Terminal base | 1794-TB2, 1794-TB3, 1794-TB3S, 1794-TBN, and 1794-TBKD |
| ON state Voltage, min | 6VDC |
| ON state Voltage, max. | 26.4VDC |
| ON state Voltage, nom | 24VDC |
| Enclosure | Open-type |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
