1769-IF4I
CompactLogix 4 Pt A/I C and V Iso Module
4 Channel Analog Current/Voltage Isolated Input Module
| Technical specifications for 1769-IF4I | |
| Manufacturer | Allen Bradley |
| Product Type | Analog Input Module |
| Product Line | CompactLogix |
| Part Number | 1769-IF4I |
| UPC | 781180908637 |
| Weight | 0.44 lbs (0.20 kg) |
| Module Type | Isolated Analog Input Module |
| Input Type | Analog Input |
| No. of Inputs | 4 Individually isolated Differential and single ended inputs |
| Power Supply Distance rating | 8 |
| Communication Cable | 4 Point |
| Input current range | 0-21 mA |
| Current signal normal ranges | 0-20mA; 4-20 mA |
| Current signal full range | 0-21 mA; 3.2 – 21 mA. |
| Series | A and B |
| Input / Output voltage range | 0-10.5VDC |
| Inputs | 4 Isolated Differential |
| Voltage signal normal ranges | ±10V DC, 0 …10V DC, 0…5V DC, 1…5V DC |
| Voltage signal full range | ±10.5V DC, -0.5…10.5V DC, -0.5…5.25V DC, 0.5…5.25V DC |
| Replacement Terminal Block | 1769-RTBN18 |
| Converter Type | Sigma-Delta |
| Resolution | 16 bits (unipolar) 15bits plus sign (bipolar) |
| Wire Type | Copper-90 degrees Celsius |
| Wire Size (Solid) | 22-14 AWG |
| Rated working voltage | 30VAC; 30VDC |
