1794-IB32
Flex 32 Point Digital Input Module
| Technical specifications for 1794-IB32 | |
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Digital Input Modules |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IB32 |
| UPC | 612598279906 |
| Weight | 0.25 lbs (0.11 kg) |
| Product Family | Flex I/O |
| ON state Voltage, min | 10VDC |
| ON state Voltage, max. | 31.2VDC |
| OFF state Voltage, max | 24VDC |
| Indicators | 32 Yellow status indicators |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Enclosure type rating | None (open-style) |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Inputs | 32 Current Sinking |
| On-state Current (minimum) | 2.0 milliamps |
| On-state Current (maximum) | 6.0 milliamps |
| Off-state Voltage (maximum) | 5 Volts DC |
| Off-state Current (maximum) | 1.5 milliamps |
| Flexbus Current | 30 milliamps at 5 Volts DC |
| Power Dissipation | 6.0 Watts at 31.2 Volts DC maximum |
