| Parameter Item | Specification |
|---|---|
| Article No. | 6AV6645-0BA01-0AX0 |
| Full Model | SIMATIC Mobile Panel 177 PN |
| Display | 5.7″ STN color screen, 320×240 resolution, resistive analog touch |
| Operating Keys | 14 programmable LED function keys, integrated acknowledgment button |
| Communication Interface | 1×RJ45 PROFINET Ethernet, 1×RS485 serial port |
| Supported Protocols | PROFINET IO, TCP/IP, Modbus TCP |
| Internal Memory | 2MB runtime memory, MMC card slot for project storage |
| Configuration Software | WinCC Flexible Compact V2005+, TIA Portal V11~V14 (Comfort/Advanced/Professional) |
| Runtime Languages | Max 5 online runtime languages, 32 project languages |
| Alarm Capacity | 2000 bit alarms, 50 analog alarms, 32 alarm classes |
| Protection Grade | IP65 front housing |
| Mechanical Specs | Φ245mm × depth 58mm, net weight 1.3kg, max drop height 1.5m |
| Operating Temp | 0 ℃ ~ +40 ℃; storage temp -20 ℃ ~ +60 ℃ |
| Humidity | Max 80% non-condensing relative humidity |
| Certifications | CE, cULus, RCM |
| OS Platform | Embedded Windows CE system |
| Lifecycle Status | Discontinued PM410, available as spare part only |
| Origin | Germany Siemens factory |
