PSTX300-600-70 600V 300A
Softstarter – 300 A – 208 … 600 V AC
| Item | Specification Value |
|---|---|
| Model | PSTX300-600-70 |
| Order Code | 1SFA898114R7000 |
| Product Type | Full-featured soft starter |
| Main Circuit Voltage | 208–600 V AC, 50/60 Hz |
| Control Supply Voltage | 100–250 V AC / 24 V DC |
| Rated Operational Current (in-line) | 300 A |
| Rated Operational Current (inside delta) | 515 A |
| Motor Power @400V (in-line) | 160 kW |
| Motor Power @400V (inside delta) | 257 kW |
| Motor Power @230V (in-line) | 90 kW |
| Motor Power @230V (inside delta) | 160 kW |
| Motor Power @500V (in-line) | 200 kW |
| Motor Power @500V (inside delta) | 355 kW |
| Max Starting Capacity | 4×Ie for 10 seconds |
| Ramp Time Range (Start/Stop) | 1–120 s |
| Initial Starting Voltage | 30%–99% Ue |
| Current Limit Range | 1.5–7.5×Ie |
| Built-in Bypass Contactor | Yes |
| Electronic Overload Protection | Integrated |
| Standard Communication | Modbus-RTU |
| Optional Communication Modules | Profinet, EtherNet/IP, DeviceNet, Modbus-TCP |
| Main Unit Protection Class | IP00 |
| Separate Keypad Protection Class | IP66 |
| Operating Ambient Temperature | -25 °C ~ +60 °C |
| Storage Temperature | -40 °C ~ +70 °C |
| Overall Dimensions (H×W×D) | 470 mm × 258 mm × 279 mm |
| Net Weight | 15.5 kg |
| Terminal Tightening Torque | 28 N·m |
| Certifications | CE, UL, CSA, IEC 60947-4-2 |
