| Parameter | Specification |
|---|---|
| Model Number | 6AV7240‑7AC06‑0PA0 |
| Product Type | SIMATIC IPC477D Panel PC |
| Display Size | 15‑inch TFT Resistive Touch Screen |
| Display Resolution | 1280 × 800 pixels |
| Backlight MTBF | 30000 hours @25 °C |
| Processor | Intel Core i5‑6442EQ, 4‑core 1.9 GHz (burst up to 2.7 GHz), 6 MB cache |
| Main Memory | 16 GB DDR4‑SDRAM |
| Storage | 240 GB SATA‑SSD |
| Operating System | Without operating system |
| Graphics Controller | Intel HD Graphics 530 |
| Ethernet Interface | 3 × 10/100/1000 Mbps RJ45 (PROFINET IRT with integrated switch) |
| USB Ports | 4 × USB3.0 (rear panel), 1 × USB3.0 (front panel) |
| Serial Interface | 2 × isolated RS232/RS485 |
| Expansion Slot | 1 × PCIe x4 slot |
| Power Supply | 24 V DC, range 19.2 V … 28.8 V DC |
| Protection Class | Front IP65; Rear IP20 |
| Cooling | Fan‑less passive cooling |
| Operating Temperature | 0 °C … +50 °C |
| Storage / Transport Temperature | ‑20 °C … +60 °C |
| Dimensions (W×H×D) | 370 mm × 300 mm × 85 mm |
| Weight | 4.9 kg |
| Certifications | CE, UL/cUL, RCM |
| Product Status | Obsolete, spare‑part supply available |
